Sony DT 50mm f/1.8 SAM Lens

      Photo Review 8.5

      In summary

      A fast 50mm prime lens designed for Sony’s Alpha DSLRs with APS-C sized sensors.The DT 50mm f/1.8 SAM lens was introduced as one of four lenses announced with the A230, A330 and A380 DSLR cameras in early May 2009. The DT 50mm f/1.8 SAM lens is the first DT prime lens Sony has introduced and it’s being promoted as a ‘portrait’ lens. This is logical because it provides a focal length equivalent to 75mm (in 35mm format) when mounted on ‘APS-C’ camera bodies. . . [more]

      Full review


      The DT 50mm f/1.8 SAM lens was introduced as one of four lenses announced with the A230, A330 and A380 DSLR cameras in early May 2009. The DT 50mm f/1.8 SAM lens is the first DT prime lens Sony has introduced and it’s being promoted as a ‘portrait’ lens. This is logical because it provides a focal length equivalent to 75mm (in 35mm format) when mounted on ‘APS-C’ camera bodies.

      The fast f/1.8 maximum aperture makes it two to three f-stops faster than any kit lens. This is a big advantage for photographers who enjoy shooting in low light levels and don’t want to use flash fill for shots. The wide aperture is also great for differential focusing with portrait shots.


      Sony’s new DT 50mm f/1.8 SAM lens, shown in side view. (Source: Sony.)

      The optical design contains six elements in nine groups and no mention is made of exotic glass elements or special coatings to improve overall performance. However, a glance at the front element will show some kind of multi-coating has been applied. This lens is made almost entirely of plastic with a plastic mounting plate and barrel. A narrow metal ring around the barrel, approximately 15mm back from the front of the lens, is the only indicator of any other materials used in construction.
      Build quality is good for a plastic lens carrying the ‘Made in China’ label. The plastic barrel has smooth satin-like finish. No lens hood is supplied – and none appears to be available. All you receive in the box are front and end caps plus several multi-lingual instruction leaflets.

      An AF/MF slider switch is located on the left side of the barrel. The focusing ring is approximately 10 mm wide, with a rubberised tip that lacks ridges for a secure grip. It’s rather loose, making precise focusing tricky. However, all focusing is internal, which means you can use angle-critical filters without having to re-adjust them when focus changes.

      Engraved along the trailing edge of this ring are distance markings in metres and feet, ranging from 0.34 metres (the close focusing limit) to infinity. The focusing ring rotates through a little more than 90 degrees when covering this distance.

      The filter ring lies inside the focusing ring and doesn’t rotate when the lens is being focused, making use of angle-critical attachments like polarisers viable. The ring accepts 49 mm diameter filters.
      The Smooth Autofocus Motor (SAM) didn’t appear to provide any particular advantages in either AF speed or operational noise. There’s a distinct buzzing sound as the lens focuses and it took almost 0.8 seconds to readjust focus from a close subject to infinity. However, focusing was generally accurate as we recorded few missed shots in our tests – even though they were conducted with a full-frame camera.

      Imatest showed the review lens to be capable of relatively high resolution on the DSLR-A850 camera body (for which it wasn’t designed). However, edge softening was quite pronounced at aperture settings up to f/16 (which covers most of the aperture range. The disparity between centre and edge resolution was greatest at wide apertures.

      Highest resolution figures for both centre and edge-of-field were found at f/5.6. Diffraction reduced resolution from about f/16 on, having a greater effect on centre resolution than edge resolution. The graph below shows the results of our Imatest tests.


      Lateral chromatic aberration was consistently negligible throughout the aperture range and we found no significant coloured fringing in our test shots. The graph below shows the results of our Imatest tests. (The red line marks the boundary between ‘negligible’ and ‘low’ CA.)


      Flare was generally well-controlled and distortion was low enough to be negligible in test shots. However, vignetting was apparent in shots taken at f/1.8, although largely resolved by f/2.8. Bokeh was quite attractive, provided backgrounds weren’t busy. With close, busy backgrounds, some highlights appeared to show edge emphasis that detracted from an otherwise attractive appearance.

      Buy this lens if:
      – You want an affordable, fast lens for available light photography.
      – You’d like superior depth-of-field control for portrait photography.
      – You require distortion-free images.
      – You’d like good performance with backlit shots.
      Don’t buy this lens if:
      – You’re using a body with a ‘full frame’ sensor.
      – You require a lens that can deliver consistent corner-to-centre sharpness.
      – You require quiet autofocusing.
      – You require rugged construction.





      ISO 100, 1/320 second at f/7.1.


      An enlarged crop from the corner of the above image, showing edge softening.


      For comparison, a crop from the centre of the same image.

      Depth of field examples with different aperture settings are shown in the four sample images below:










      Vignetting at f/1.8 (ISO 100, 1/5000 second exposure).


      Vignetting at f/2.8 (ISO 100, 1/2000 second exposure).


      Compositional problems when this lens is mounted on a ‘full frame’ DSLR body. It’s difficult to avoid cropping the top of the subject’s head because no frame guides are provided in the camera’s viewfinder – even though the lens is usable on the camera body. ISO 100, 1/60 second at f/2.2.


      ISO 100, 1/400 second at f/7.1.


      ISO 100, 1/80 second at f/5.


      Bokeh with a distant background: ISO 100, 1/1000 second at f/1.8.


      Bokeh with a close and busy background: ISO 100, 1/2500 second at f/2.


      Detail and edge effects; ISO 100, 1/250 second at f/10.


      Enlarged crop from the above image showing minimal coloured fringing.


      Backlighting; ISO 100, 1/640 second at f/4.

      Additional image samples can be found with the review of the Sony DSLR-A850 camera.




      Picture angle: 32 degrees (with APS-C sensor)
      Maximum aperture: f/1.8
      Minimum aperture: f/22
      Lens construction: 6 elements in 9 groups
      Lens mount: Sony Alpha and Minolta AF
      Diaphragm Blades: 7 (circular aperture)
      Focus drive: Smooth Autofocus Motor (SAM)
      Minimum focus: 34 cm
      Maximum magnification: 0.2x
      Filter size: 49 mm
      Dimensions (Diameter x L): 70 x 45 mm
      Weight: Approx. 170 grams





      Digital cameras, lenses and accessories with 100% genuine Australian manufacturer’s warranties.
      Ph: (02) 9029 2219

      Camera House


      Ph: 133 686
      The largest speciality photographic retail chain in Australia.

      Camera Pro

      CameraPro Pty Ltd
      Suite 607, 180 Queen St, Brisbane 4000
      Tel: 07 3333 2900
      Australian owned and run company based in Brisbane.



      Retailer of digital camera equipment and more.
      Secure online shopping and delivery across Australia.
      Ph: 1300 727 056
      Ph: 1800 155 067



      Comprehensive range of digital cameras and accessories online ( and an online print service (

      Digital Camera Warehouse

      174 Canterbury Road 367 High Street
      Canterbury Northcote
      NSW 2193 VIC 3070
      Ph: 1300 365 220

      Electronics Warehouse

      1300 801 885
      Australian retailer of Vapex rechargeable batteries offering factory direct prices and fast, free shipping Australia wide.



      Photographic Equipment & Supplies – Retail & Repairs. Click here for list of stores.

      Ted’s Cameras



      1800 186 895
      Big range of cameras and photographic products with stores in most states and online.



      RRP: $299

      Rating (out of 10):

      • Build: 8.5
      • Handling: 8.5
      • Image quality: 8.5
      • Versatility: 7.5
      • OVERALL: 8.5
